Click model # for parts breakdown
| Model | Flow | Pressure | Plunger Diameter | Crankshaft | Power | Seal Kit | Valve Kit | Weight | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| GPM | L/MIN | PSI | BAR | Stroke | Code | |||||||
| 1450 RPM | AKC 09/25 S | 2.4 | 9.0 | 3625 | 250 | 15mm | 12.5mm | S | 5.6 EBHP | 6061.07 | 6061.02 | 15 lbs |
| AKC 10/25 S | 2.6 | 10.0 | 3625 | 250 | 15mm | 14.0mm | 7 | 6.3 EBHP | 6061.07 | 6061.02 | 15 lbs | |
| AKC 11/25 S | 2.9 | 11.0 | 3625 | 250 | 18mm | 10.5mm | O | 7.0 EBHP | 6061.E2 | 6061.02 | 15 lbs | |
| AKC 12/25 S | 3.2 | 12.0 | 3625 | 250 | 18mm | 11.5mm | R | 7.7 EBHP | 6061.E2 | 6061.02 | 15 lbs | |
| AKC 14/25 S | 3.7 | 14.0 | 3625 | 250 | 18mm | 12.5mm | S | 8.6 EBHP | 6061.E2 | 6061.02 | 15 lbs | |
| AKC 15/25 S | 4.0 | 15.0 | 3625 | 250 | 18mm | 14.0mm | 7 | 9.8 EBHP | 6061.E2 | 6061.02 | 15 lbs | |
| 1750 RPM | AKD 3.0/36 S | 3.2 | 12.0 | 3625 | 250 | 15mm | 14.0mm | 7 | 7.9 EBHP | 6061.07 | 6061.02 | 15 lbs |
| AKD 3.5/36 S | 3.5 | 13.2 | 3625 | 250 | 18mm | 10.5mm | O | 8.5 EBHP | 6061.E2 | 6061.02 | 15 lbs | |
| AKD 4.0/36 S | 4.0 | 15.0 | 3625 | 250 | 18mm | 12.5mm | S | 10.5 EBHP | 6061.E2 | 6061.02 | 15 lbs | |
| Rail Kit | 8702.10 | Standard 7/8″ Rail Kit for PN, A, AK, B & BK Series Solid Shaft Pumps | ||||||||||
| NOTE: All pump models available with left-hand drive option. Add ‘L’ to model number when ordering (ex. AC 11/20 SL) | ||||||||||||
