6-Cylinder, Low-Pressure Diaphragm Pumps
ZETA 260 low pressure 6-cylinder diaphragm pumps have anodized aluminum bodies with plasticized aluminum heads, stainless steel valves and glass-filled nylon manifolds.
ZETA 260 pumps are excellent for various horticultural and agricultural spraying applications.
Pumps are available with a 1-3/8″ Male PTO thru-shaft or 2-bolt A-flange hydraulic motor mount with 1″ hollow shaft.
| Specifications | ZETA 230 | ZETA 260 |
| Inlet Port | 2″ Hose Barb | 2″ Hose Barb |
| Outlet Ports – Valve | 1-1/2″ Hose Barb | 1-1/2″ Hose Barb |
| Piston Diameter | 75.0mm | 75.0mm |
| Crankshaft Stroke/Code | 16.0mm/X | 18.0mm/E |
| Dimensions – Pump Only | 14.5″L x 15.5″W x 18.5″H | |
| Lubrication: Requires 90 oz. of Udor Lube 40W Premium Pump Oil. Alternate Oil: 30W non-detergent or 15W-40 non-detergent oil. |
||
| Repair Kits | Part # |
| Diaphragm Kit – GREENTECH | 6062.H4 |
| Diaphragm Bolt & Washer Kit | 6062.28 |
| Valve Kit | 6062.D3 |
| Complete Repair Kit | 8700.44CK |
